Price Tag App

A step-by-step walkthrough of building a price tag designer with custom layers, a nested canvas product layout, and a read-only grid view.

This page walks through the key parts of the Price Tag app — a real-world example of how to extend Waraq with custom layer types, nest one Waraq canvas inside another, and render a read-only grid of saved designs.

/waraq/price-tag/template/price-tag-1 Open

1. QR Code layer

A QR code layer renders an SVG QR code from layer.value. It uses the lightweight render function form (no hooks needed).

import type { LayerType } from "@codecanon/waraq/lib";
import { QRCodeSVG } from "qrcode.react";
import { IconQrcode } from "@tabler/icons-react";

export interface QRCodeLayerData {
  qrLevel?: "L" | "M" | "Q" | "H";
  qrFgColor?: string;
}

export const QRCodeLayerType: LayerType<QRCodeLayerData> = {
  id: "qrcode",
  name: "QR Code",
  keepRatio: true,
  icon: <IconQrcode size={16} />,
  render: (layer) => {
    const value = layer.value || "https://example.com";
    const qrLevel = layer.data?.qrLevel || "M";
    const qrFgColor = layer.data?.qrFgColor || "#000000";

    return (
      <QRCodeSVG
        bgColor="transparent"
        value={value}
        level={qrLevel}
        fgColor={qrFgColor}
        style={{ ...layer.contentStyle, width: "100%", height: "100%" }}
      />
    );
  },
  defaultValues: {
    value: "https://example.com",
    cssVars: {
      "--width": "200px",
      "--height": "200px",
      "--background-color": "#ffffff",
    },
    data: { qrLevel: "M", qrFgColor: "#000000" },
  },
  keyboardShortcut: {
    description: "Add QR Code",
    keys: ["Q"],
    action: (context) => context.addLayer("qrcode"),
    category: "Layer",
  },
};

The keepRatio: true flag locks the aspect ratio when resizing. layer.contentStyle applies the resolved CSS vars (padding, alignment, etc.) to the inner element.

2. Input layer

The input layer renders an editable <input> or <textarea> directly on the canvas. It uses the Component form so it can call useWaraq to push value changes back.

import { useWaraq } from "@codecanon/waraq";
import type { LayerType } from "@codecanon/waraq/lib";
import { IconTextSize } from "@tabler/icons-react";
import { useState } from "react";

export interface InputLayerData {
  placeholder?: string;
  multiLine?: boolean;
  defaultValue?: string;
}

export const InputLayerType: LayerType<InputLayerData> = {
  id: "input",
  name: "Input",
  icon: <IconTextSize size={16} />,
  Component({ layer }) {
    const [focused, setFocused] = useState(false);
    const { updateLayer } = useWaraq();

    const value = layer.value || "";
    const defaultValue = layer.data?.defaultValue;
    const displayValue = focused ? value : value.trim() || defaultValue;
    const Comp = layer.data?.multiLine ? Textarea : Input;

    return (
      <Comp
        style={layer.contentStyle}
        value={displayValue}
        placeholder={layer.data?.placeholder}
        onFocus={() => setFocused(true)}
        onBlur={() => setFocused(false)}
        onChange={(e) => updateLayer({ id: layer.id, value: e.target.value })}
      />
    );
  },
  defaultValues: {
    value: "",
    cssVars: {
      "--width": "300px",
      "--height": "60px",
      "--font-size": "16px",
      "--padding-top": "12px",
      "--padding-bottom": "12px",
      "--padding-left": "16px",
      "--padding-right": "16px",
    },
    data: { placeholder: "Enter text...", multiLine: false },
  },
  keyboardShortcut: {
    description: "Add Input",
    keys: ["⌘", "I"],
    action: (context) => context.addLayer("input"),
    category: "Layer",
  },
};

useWaraq() gives access to updateLayer, addLayer, and the rest of the editor state. It can only be called from a component rendered inside <Waraq>.

3. Product layer — a canvas within a canvas

The product layer is the most advanced: when the display style is "custom", each product is rendered by its own nested Waraq canvas (WaraqProvider + WaraqStaticFrame). This lets the user design a mini price-tag template that is stamped out once per product.

3a. Layer type definition

import type { WaraqData, LayerType } from "@codecanon/waraq/lib";
import { IconShoppingCart } from "@tabler/icons-react";

export interface ProductDisplay {
  id: string;
  name: string;
  sku: string;
  price: number;
  image?: string;
}

export interface ProductLayerData {
  displayStyle: "card" | "grid" | "table" | "list" | "custom";
  products: ProductDisplay[];
  customDesign?: WaraqData;           // the shared template canvas
  productDesign?: Record<string, WaraqData>; // per-product override
  maxSelectCount?: number;
}

export const ProductLayerType: LayerType<ProductLayerData> = {
  id: "product",
  name: "Products",
  icon: <IconShoppingCart size={16} />,
  Component({ layer }) {
    const displayStyle = layer.data?.displayStyle || "card";
    const products = layer.data?.products || [];

    return (
      <div style={layer.contentStyle}>
        {products.length === 0 ? (
          <ProductEmptyView />
        ) : displayStyle === "custom" ? (
          <ProductCustomView layer={layer} />
        ) : (
          // … other display styles (card, grid, table, list)
        )}
      </div>
    );
  },
  defaultValues: {
    cssVars: { "--width": "500px", "--height": "300px" },
    data: { displayStyle: "card", products: [] },
  },
  keyboardShortcut: {
    description: "Add Product",
    keys: ["P"],
    action: (context) => context.addLayer("product"),
    category: "Layer",
  },
};

3b. Custom view — nested canvases

ProductCustomView spins up a separate WaraqProvider for every product, feeds it the shared customDesign canvas data, and passes the current product in via injectLayerData. The static frame then renders that design as a read-only tile.

import {
  WaraqProvider,
  WaraqStaticFrame,
  useWaraq,
} from "@codecanon/waraq";
import type { Layer } from "@codecanon/waraq/lib";
import type { ProductLayerData } from "./price-tag-product-layer-type";
import { PRODUCT_CUSTOM_LAYER_TYPES } from "./product-custom-layer-types";

export function ProductCustomView({
  layer,
}: {
  layer: Layer<ProductLayerData>;
}) {
  const { updateLayer } = useWaraq();

  return (
    <div className="flex size-full flex-row flex-wrap content-start overflow-auto gap-2">
      {layer.data!.products.map((product) => {
        // Use per-product override if it exists, otherwise fall back to shared template
        const design =
          layer.data!.productDesign?.[product.id] || layer.data!.customDesign;

        return (
          <WaraqProvider
            key={product.id}
            data={design}
            layerTypes={PRODUCT_CUSTOM_LAYER_TYPES}
            onDataChange={(newDesign) => {
              updateLayer({
                id: layer.id,
                data: {
                  ...layer.data,
                  productDesign: {
                    ...layer.data!.productDesign,
                    [product.id]: newDesign,
                  },
                },
              });
            }}
          >
            {/* injectLayerData makes `layer.data.product` available to every
                product-* layer type inside this canvas */}
            <WaraqStaticFrame
              className="shrink-0 shadow-none"
              injectLayerData={() => ({ product })}
            />
          </WaraqProvider>
        );
      })}
    </div>
  );
}

Key points:

WaraqProvider is the headless provider — it holds the canvas state without rendering any UI chrome.
WaraqStaticFrame renders the canvas read-only, no drag or resize handles.
injectLayerData merges extra data into every layer at render time. The product-specific layer types (product-name, product-price, product-image, …) read layer.data.product to show the right values.

3c. Product-specific layer types

Inside the custom product canvas you register specialised layer types that pull data from layer.data.product. These layer types are only passed to the inner WaraqProvider, not the outer editor.

import type { LayerType } from "@codecanon/waraq/lib";
import { IconTag, IconHash, IconCurrencyDollar, IconPhoto } from "@tabler/icons-react";
import type { ProductDisplay } from "./price-tag-product-layer-type";

interface ProductPropertyLayerData {
  product?: ProductDisplay;
}

export const ProductNameLayerType: LayerType<ProductPropertyLayerData> = {
  id: "product-name",
  name: "Product Name",
  icon: <IconTag size={16} />,
  render: (layer) => (
    <span style={layer.contentStyle}>
      {layer.data?.product?.name || "Product Name"}
    </span>
  ),
  defaultValues: {
    cssVars: { "--width": "450px", "--height": "41px", "--font-size": "24px", "--font-weight": "600" },
  },
};

export const ProductPriceLayerType: LayerType<ProductPropertyLayerData> = {
  id: "product-price",
  name: "Product Price",
  icon: <IconCurrencyDollar size={16} />,
  render: (layer) => {
    const price = layer.data?.product?.price;
    return (
      <span style={layer.contentStyle}>
        {price != null ? `$${price.toFixed(2)}` : "$0.00"}
      </span>
    );
  },
  defaultValues: {
    cssVars: { "--width": "161px", "--height": "60px", "--font-size": "28px", "--font-weight": "700", "--color": "#10b981" },
  },
};

// ProductSKULayerType, ProductImageLayerType follow the same pattern.

4. Registering all custom layer types

Collect your custom types and spread them after DEFAULT_LAYER_TYPES:

import { DEFAULT_LAYER_TYPES } from "@codecanon/waraq/lib";
import type { LayerType } from "@codecanon/waraq/lib";
import { InputLayerType } from "./price-tag-input-layer-type";
import { QRCodeLayerType } from "./price-tag-qrcode-layer-type";
import { ProductLayerType } from "./price-tag-product-layer-type";

export const PRICE_TAG_LAYER_TYPES: LayerType[] = [
  ...DEFAULT_LAYER_TYPES,
  InputLayerType,
  QRCodeLayerType,
  ProductLayerType,
];

Then pass this array to <Waraq>:

import { Waraq, WaraqStage, WaraqFrame } from "@codecanon/waraq";
import { PRICE_TAG_LAYER_TYPES } from "./price-tag-layer-types";

export function PriceTagEditor() {
  return (
    <Waraq layerTypes={PRICE_TAG_LAYER_TYPES}>
      <WaraqStage>
        <WaraqFrame />
      </WaraqStage>
    </Waraq>
  );
}

5. Price tag grid — read-only display with `WaraqStaticFrame`

The grid page shows all saved designs as thumbnail cards. Each card uses WaraqPreview to scale the frame to fit its container, then WaraqStaticFrame to render the layers without any editor interactivity.

import {
  WaraqPreview,
  WaraqStaticFrame,
} from "@codecanon/waraq";
import { PRICE_TAG_LAYER_TYPES } from "./price-tag-layer-types";
import type { PriceTag } from "@/types/price-tag";

function PriceTagCard({ priceTag }: { priceTag: PriceTag }) {
  return (
    <div className="flex flex-col gap-2">
      {/* WaraqPreview computes a scale transform so the frame fills the card */}
      <WaraqPreview frameSize={priceTag.frameSize}>
        {(style) => (
          <WaraqStaticFrame
            data={priceTag}
            layerTypes={PRICE_TAG_LAYER_TYPES}
            style={style}
          />
        )}
      </WaraqPreview>

      <p className="text-sm font-medium">{priceTag.name}</p>
    </div>
  );
}

WaraqStaticFrame takes data (a WaraqData object) and layerTypes directly — there is no surrounding <Waraq> provider required. This makes it ideal for thumbnails, print previews, and read-only embeds.
